Getting started with POPACheck

28 July 2025 - 8 mins read time
Tags: Tutorial

In this post we explain how to download and install POPACheck to get started with analyzing probabilistic programs.

The easy way (GNU/Linux and Windows)

You may download the pre-packaged OPPAS executable files from the GitHub release.

The instructions below will work on a GNU/Linux terminal. If you are running Windows, you will need to install the Windows Subsystem for Linux (WSL). Please follow the installation instructions by Microsoft. Once WSL is installed, setup and open a terminal.

If you are using GNU/Linux, you may open a terminal and proceed directly.

First extract the files from the archive with your favorite program. For instance, open a terminal and run

mkdir oppas
tar -xvf oppas-3.0.0-x86_64.tar.gz -C oppas

The above command creates a new directory named oppas, and extracts the files into it.

Getting started

Among the files extracted from the archive, you’ll find the popacheck executable.

Let’s do a couple of quick checks to see if it works.

First, just run

./popacheck --help

This will print something like

POPACheck v3.0.0

followed by the usage instructions. You may ignore the command-line flags listed below, as they toggle advanced settings that most users won’t need to touch.

A few experiments

Input Format

POPACheck must be invoked by supplying an input file as its only argument. Input files follow this format:

probabilistic query: <QUERY>;
program:
...

POPACheck supports several kinds of queries. For now, we’ll just focus on approximate queries, which compute an approximate lower and upper bound for the termination probability of the first function in the program specified in the file.

A simple program

Let’s try with a very simple file: open your favorite text editor and paste the following text into it:

probabilistic query: approximate;
program:
f () { }

This program contains only an empty function, and we ask POPACheck for its termination probability. Then save it as test.pomc and run

./popacheck test.pomc

POPACheck should output the following:

Probabilistic Termination Checking
Query: ApproxSingleQuery OVI Newton
Result:  ApproxSingleResult (1 % 1,1 % 1)
Elapsed time: 7.005 ms (total), 0.0000e0 s (upper bounds), 0.0000e0 s (PAST certificates), 0.0000e0 s (graph analysis).
Input pOPA state count: 4
Support graph size: 5
Equations solved for termination probabilities: 3
Non-trivial equations solved for termination probabilities: 0
SCC count in the support graph: 7
Size of the largest SCC in the support graph: 1
Largest number of non trivial equations in an SCC in the Support Graph: 0

This output is quite verbose and contains many details that we don’t need to care about. The important bits are the following:

• Probabilistic Termination Checking says that POPACheck is checking the termination probability of the given program
• Result: ApproxSingleResult (1 % 1,1 % 1) shows the computed lower and upper bounds for the termination probability as fractions of two integer numbers. Thus, 1 % 1 means \(\frac{1}{1}\), hence the program terminates with probability \(1\).

Coin flip

Let’s try with a slightly less trivial program:

probabilistic query: approximate;
program:
f () {
  bool x;
  x = true {1 : 2} false;
  while (x) {
    x = x;
  }
}

This program consists of a function that declares a Boolean (bool) variable x, and “flips a coin”: it assigns to x the value true with probability \(\frac{1}{2}\) (1 : 2), and false with probability \(\frac{1}{2}\). Then, it enters an infinite loop if the coin flip returned true.

If we run POPACheck on it, we get the following:

Probabilistic Termination Checking
Query: ApproxSingleQuery OVI Newton
Result:  ApproxSingleResult (1 % 2,1 % 2)
Elapsed time: 7.713 ms (total), 0.0000e0 s (upper bounds), 0.0000e0 s (PAST certificates), 0.0000e0 s (graph analysis).
Input pOPA state count: 7
Support graph size: 10
Equations solved for termination probabilities: 7
Non-trivial equations solved for termination probabilities: 0
SCC count in the support graph: 16
Size of the largest SCC in the support graph: 1
Largest number of non trivial equations in an SCC in the Support Graph: 0

Indeed, the program terminates if and only if the coin flip returns false, an event which has probability \(\frac{1}{2} = 0.5\).

Flipping coins in a loop

What if we move the coin flip into the loop? Let’s feed to POPACheck the following file:

probabilistic query: approximate;
program:
f () {
  bool x;
  x = true {1 : 2} false;
  while (x) {
    x = true {1 : 2} false;
  }
}

This program has essentially the following meaning:

Keep flipping a coin, and stop the first time you get tails (false in the program).

In this case, we get

Probabilistic Termination Checking
Query: ApproxSingleQuery OVI Newton
Result:  ApproxSingleResult (1 % 1,1 % 1)
Elapsed time: 9.468 ms (total), 2.3829e-4 s (upper bounds), 1.4550e-3 s (PAST certificates), 0.0000e0 s (graph analysis).
Input pOPA state count: 8
Support graph size: 11
Equations solved for termination probabilities: 9
Non-trivial equations solved for termination probabilities: 1
SCC count in the support graph: 19
Size of the largest SCC in the support graph: 1
Largest number of non trivial equations in an SCC in the Support Graph: 1

Hence the termination probability of the program is again \(1\), or it terminates almost surely. This is not surprising: the program exists the loop as soon as the coin flip in it returns false. Although the probability of this event to happen in any individual coin flip is lower than \(1\), the more times we flip the coin (i.e., run the loop) the higher the probability of getting false at least once. Hence, as the number of loop iterations approaches infinity, the probability of exiting the loop (and terminating the program) approaches \(1\).

Let’s understand this phenomenon better by thinking at our coin flipping analogy. Suppose you flip a coin once: the probability of getting heads is \(\frac{1}{2}\). If you get heads, you do one more flip. The probability of this second flip being heads is again \(\frac{1}{2}\), because the result of the first flip does not influence the second. The two flips are independent.

But let’s go back to before we started flipping the coin. What is the probability that we will do at least three coin flips? According to our “algorithm”, we must get heads in both the first two flips. All possible outcome combinations are listed in the following table:

where H represents heads, and T tails. There are 4 possible outcomes, but we are interested in only one, namely H H. The probability of two heads happening consecutively is hence one over four, or \(\frac{1}{4}\). The same result can be obtained by multiplying the probabilities of the two individual events: \[\frac{1}{2} \cdot \frac{1}{2} = \frac{1}{4}\]

This formula can be generalized to obtain the probability of throwing \(n\) consecutive heads as follows: \[ \underbrace{\frac{1}{2} \cdot \frac{1}{2} \cdots \frac{1}{2}}_{n \text{ times}} = \left(\frac{1}{2}\right)^n \]

But we are actually interested in the event that the loop in our program terminates. More precisely, let us consider the event that the loop terminates within \(n\) coin flips. This event happens if at least one of our throws results in tails, which is exactly the opposite of getting heads in all flips. For two coin flips, this represents all outcomes except the first row, hence three over four, or \(\frac{1}{4} = 1 - \frac{1}{4}\). We can generalize this formula to \(n\) throws: \[ 1 - \left(\frac{1}{2}\right)^n. \]

Let us see how these probability evolve as we do more loop iterations (or coin flips), and \(n\) becomes larger:

As we can see, as the number of throws increases, the probability of getting only heads decreases until it becomes practically \(0\), while that of getting at least one tails gets closer and closer to \(1\). Hence, the probability of exiting the loop gets closer to \(1\) with each iteration, and we can say that the loop (and the program) terminates almost surely.

This phenomenon is known as the second Borel–Cantelli lemma, and it is a consequence of the well-known Law of Large Numbers.

Keep following this blog posts series to discover more interesting facts about random phenomena, and how to reason on them with POPACheck.
