The Fish Bowl

This post is part of a series of posts explaining some basic concepts of probability theory with the help of POPACheck. Check out the first post here.

A piranha in a fishbowl

In this post we will explore conditioning, a very important concept in probability theory. We’ll do so with the help of the following problem:

One fish is contained within the confines of an opaque fishbowl. The fish is equally likely to be a piranha or a goldfish. A sushi lover throws a piranha into the fish bowl alongside the other fish. Then, immediately, before either fish can devour the other, one of the fish is blindly removed from the fishbowl. The fish that has been removed from the bowl turns out to be a piranha. What is the probability that the fish that was originally in the bowl by itself was a piranha?

taken from Henk Tijms, Understanding Probability: Chance Rules in Everyday Life. Cambridge University Press, 2007.

Solving the problem with POPACheck

We can model this problem as a probabilistic program in MiniProb, the input language of POPACheck, and then let POPACheck do the math.

We use two Boolean variables, f1 and f2, to represent the two fish: f1 is the fish that was already in the bowl, and f2 is the one we throw in. Each variable takes the value true if the corresponding fish is a piranha, and false if it is a goldfish. For instance, if f1 = false and f2 = true, then the bowl contained a goldfish, and the fish we threw in was a piranha.

First, we state the fact that the fish in the bowl is equally likely to be a piranha or a goldfish by stating that variable f1 is equally likely to be initially true or false. We do so with a probabilistic assignment:

f1 = true {1 : 2} false;

which assigns to f1 respectively true or false with probability \(\frac{1}{2}\).

Then we “put” a piranha in the bowl by deterministically assigning true to f2:

f2 = true;

Finally, we simulate extracting one fish: we are equally likely to get anyone of the two fish in the bowl, so we represent the extracted fish with a new Boolean variable called extracted, to which we assign the value of either f1 or f2 both with probability \(\frac{1}{2}\):

extracted = f1 {1 : 2} f2;

The entire program is the following:

fish() {
  bool f1, f2, extracted;
  f1 = true {1 : 2} false;
  f2 = true;
  extracted = f1 {1 : 2} f2;
}

We can already start asking POPACheck to tell us some interesting facts about the program. For instance, what is the probability that we extract a piranha, at this point? We create a new text file with the following content:

probabilistic query: quantitative;
formula = F (ret And fish And [fish | extracted == true]);
program:
fish() {
  bool f1, f2, extracted;
  f1 = true {1 : 2} false;
  f2 = true;
  extracted = f1 {1 : 2} f2;
}

Here we are asking POPACheck to approximately determine the probability that a certain property is true about the program. The property is written as a formula in Linear Temporal Logic, a mathematical formalism often used to reason about programs. The formula is

F (ret And fish And [fish | extracted == true])

The F operator is called Finally or Eventually, and it means that at some point the sub-formula to its right must be true. The formula to its right says that three things must be true together: ret, which means that a function returns, fish, which means that the currently active function is fish (the only one we have in this program), and [fish | extracted == true], which means that the variable extracted must have the value true. The last one could have also been written as [fish | extracted], a syntax more familiar to programmers. To sum up, we ask POPACheck for the probability that at some point function fish returns with extracted = true. POPACheck prints the following:

Quantitative Probabilistic Model Checking
Query: F ((ret And fish) And [fish| extracted])
Result:  (3 % 4,3 % 4)
Floating Point Result:  (0.75,0.75)
...

Thus, the probability of extracting a piranha is \(\frac{3}{4}\), or \(0.75\).

What is the probability of extracting a goldfish? We just change [fish | extracted == true] (or [fish | !extracted] for programmers) in the file, and POPACheck outputs:

Quantitative Probabilistic Model Checking
Query: F ((ret And fish) And [fish| ! extracted])
Result:  (312500 % 1250001,1 % 4)
Floating Point Result:  (0.24999980000016,0.25)

The probability is indeed \(\frac{1}{4}\).

But the problem statement asked us something a bit more complicated. It assumes that when we draw the fish, we get a piranha, and then asks us what’s the probability that the fish originally in the bowl was a piranha. In our programmatic setting, this means that we know that extracted = true, and we want to know what was the probability that f1 was assigned true.

POPACheck can help us with this. We need a new statement called observe, that tells POPACheck something that is true about the program. In our case, this has to be extracted == true (or just extracted). To properly use this statement, we need to call our function fish() with a special statement called query. It means we are querying the value of a probability distribution represented by a function. Hence we write:

probabilistic query: quantitative;
formula = F (ret And fish And [fish | f1]);
program:
main() {
  query fish();
}

fish() {
  bool f1, f2, extracted;
  f1 = true {1 : 2} false;
  f2 = true;
  extracted = f1 {1 : 2} f2;
  observe extracted;
}

Note that, this time, in the formula we have [fish | f1] because we want to know the probability that f1 was assigned true (= piranha). POPACheck outputs:

Query: F ((ret And fish) And [fish| f1])
Result:  (2 % 3,1111113 % 1666669)
Floating Point Result:  (0.6666666666666666,0.6666668666663866)

Thus, the probability that the fish initially in the bowl was a piranha is \(\frac{2}{3}\), and POPACheck has solved the problem for us.

Solving the problem manually

But what if we wanted to solve this problem ourselves? Let’s make a table! We will use 🐟 for the piranha, and 🐠 for the goldfish.

F1 F2 Extracted (which one) Extracted (Type)
🐟 🐟 F1 🐟
🐟 🐟 F2 🐟
🐠 🐟 F1 🐠
🐠 🐟 F2 🐟

By looking at the last column, we can see that the we can extract a piranha 🐟 in 3 cases over 4, hence with a probability of \(\frac{3}{4}\). Clearly, we extract a goldfish 🐠 in one case over four, hence with a probability of \(\frac{1}{4}\).

But what’s the answer to the problem statement? To get our answer, we consider only the three rows that contain a piranha in the last column, hence considering only the cases in which we extract a piranha. Among these three rows, two have a piranha in the first column, indicating that the fish already in the bowl was a piranha. These are two cases out of three, so the probability that the fish in the bowl was a piranha knowing that we extracted a piranha is \(\frac{2}{3}\).

Note that we can also obtain our result as follows: \[ \frac{\frac{2}{4}}{\frac{3}{4}} = \frac{1}{2} \cdot \frac{4}{3} = \frac{2}{3} \]

Where does \(\frac{2}{4}\) come from? It’s the joint probability that the fish already in the bowl was a piranha and that we extract a piranha (which can be any of the two fish in the bowl). We write it as \(P(\mathit{F1} = 🐟 \land \mathit{Extracted} = 🐠)\). We can easily see that it’s \(\frac{1}{2}\) by thinking that, if the fish in the bowl was a piranha, then we extract a piranha with probability one, because the fish we put in the bowl is a piranha. Hence, the joint probability is only given by the probability that the fish in the bowl was a piranha.

The probability that the problem asks us to estimate is called a conditional probability, or the probability that the fish in the bowl was a piranha conditioned on the observed fact that we extracted a piranha. We write it as \(P(\mathit{F1} = 🐟 \mid \mathit{Extracted} = 🐠)\). We have the following relation, that we can use to compute a conditional probability: \[ P(\mathit{F1} = 🐟 \mid \mathit{Extracted} = 🐠) = \frac{P(\mathit{F1} = 🐟 \land \mathit{Extracted} = 🐠)}{P(\mathit{Extracted} = 🐠)} \] where \(P(\mathit{Extracted} = 🐠)\) is the probability of extracting a piranha.

What do you think? Is it easier to come up with the argument above, or to just let POPACheck do it for us?


This blog post was inspired by an example in the article: F. Olmedo, F. Gretz, N. Jansen, B.L. Kaminski, J.-P. Katoen and A. McIver. Conditioning in probabilistic programming. ACM Transactions on Programming Languages and Systems (TOPLAS), 40(1), pp.1-50, 2028.

Keep following this blog posts series to discover more interesting facts about random phenomena, and how to reason on them with POPACheck.
